Our Hot Melt Lamination Machine delivers consistent bonding for fabrics, films, foams, and nonwovens. It combines accurate coating control with stable laminating nips to achieve uniform adhesive laydown and repeatable results. With 18+ years in adhesive machinery, we provide complete lines and practical guidance on materials, coat weights, and processing.
We pair the laminating line with formula support—adhesive selection, process window definition, and on‑site trials—so you reach target bond strength and throughput sooner.
A team of 30+ designers and 150+ employees delivers engineered systems to 20+ countries. Mechanical, electrical, and process expertise helps ensure stable running, precise coating, and repeatable lamination.
Choose slot‑die for high uniformity and closed‑loop control. Select roller coating for broad viscosity ranges. Use curtain coating for high‑speed thin films. Modular nips and temperature‑managed rollers maintain consistent bonding across different thicknesses and textures.
Servo‑driven unwind/rewind, precision web guides, and load‑cell feedback stabilize tension through coating and nip zones. This reduces curl, telescoping, and squeeze‑out for clean, defect‑free laminates.
Electric, thermal oil, or IR heating can be matched to adhesive behavior. High‑efficiency melters, heated hoses, and insulated manifolds help maintain viscosity and reduce thermal degradation.
PLC/HMI with recipe management and alarm diagnostics improves repeatability. Optional inline thickness monitoring and vision inspection detect defects early to reduce rework.
Lines are configurable from narrow to wide formats, with mechanical speeds tuned to substrate and coat weight. Sizing preserves heating capacity, tension stability, and throughput.
Handles fabrics, nonwovens, foams, leather, films (BOPP, PET, TPU), metalized foils, and paper. Adjustable nip pressure, temperature, and dwell time optimize adhesion on porous and smooth surfaces.
Supports PUR hot melt (moisture reactive), HMPSA, EVA‑based hot melt, and select acrylic hot melts. Matching melters, filtration, and coating heads to adhesive rheology keeps coat weight accurate and surfaces clean.
Configure single‑sided overlays or double‑sided multi‑layer composites. Independent heating zones and dual coating heads enable balanced bonding.
Run inline with upstream processes or downstream slitting, or offline as a dedicated cell. Connectivity supports data capture and production traceability.
PUR bonding provides heat, chemical, and creep resistance. Controlled moisture exposure and temperature profiles support cure control and dimensional stability.
Closed systems for isocyanate containment, precise degassing, and moisture management enhance safety and consistency. We supply PUR hot melt adhesive matched to line parameters for stable rheology, open time, and final strength.
Produce soft‑touch composites for apparel, footwear, and upholstery by tuning nip pressure and temperature to maintain hand feel while meeting peel strength targets.
Laminate BOPP, PET, TPU, and metalized foils to barrier or decorative layers using thin, uniform coatings. Stable heating and tension help prevent shrink and wrinkling.
Build multi‑layer structures for automotive interiors, building materials, electronics cushioning, and tapes. Use HMPSA for pressure‑sensitive performance or PUR for durability.
Share your substrates, target properties, web width, speed, and adhesive type to receive a tailored configuration. Contact us to discuss your project or request a quote.
